HS-series Internal doors
Improve your operational efficiency and save energy with ASSA ABLOY's interior high speed doors.
ASSA ABLOY high speed interior doors suit many different applications. Their unique design offers perfect sealing and makes them virtually airtight. With fast opening and closing speed, our range of high speed interior doors improve your operational efficiency and help you save energy. The absence of stiffeners combined with a flexible curtain that moulds itself, ensures high safety for personnel and equipment.
A motor driven by a frequency converter makes ASSA ABLOY high speed interior doors extremely reliable. Soft starts and stops increase the longevity of the motor considerably.
All ASSA ABLOY high speed interior doors are equipped with a break-away system. They are also self-repairing to reduce production downtime and maintenance.
ASSA ABLOY HS9010P
ASSA ABLOY HS9010P is a high speed door designed for interior use in medium-sized heavy-duty operations. To increase natural lighting, the door curtain can be equipped with windows or vision panels. A curtain with an increased static insulation is available as an option.
ASSA ABLOY HS9010PL
ASSA ABLOY HS9010PL is a large-sized high speed door for inside applications. To increase natural light, the curtain can be equipped with windows.
ASSA ABLOY HS9110P
ASSA ABLOY HS9110P is an evolution of ASSA ABLOY HS9010P. It is designed for medium-sized heavy-duty operations in interior environments. Silent, fast and smooth operation provides a high level of comfort.
ASSA ABLOY HS9020G
ASSA ABLOY HS9020G is a medium-sized high speed door suitable for a wide range of applications. To increase natural light, the door curtain can be equipped with windows or vision panels.
ASSA ABLOY HS9120G
The ASSA ABLOY HS9120G is a durable high-cycle door designed to perform in a wide range of different industries for internal applications. The door offers a range of advanced features you need from a high-performing, high-speed door and all in one aesthetic and modern design. The door helping you accelerate the flow of people and goods, while maximizing protection and ensuring a more comfortable indoor climate. It has number of safety features as standard that are essential to your operations. The safety light curtain covers the total door width up to a height of 1600 mm so if any obstructions are detected the door closing stops immediately and opens. The Break-away and automatic reset system ensures the door curtain will reintroduce itself after a crash to reduce downtime and maintenance.
The soft-bottomed profile with no rigid parts, the door will give way should an obstruction occur in the line of closing. For a higher level of hygiene, we deliver the SPOT ON opening system, a fully touchless opening system for easier entry and more hygienic operation. An other optional feature is the accoustic foam curtain. The curtain providing a high level of acoustic insulation and thermal properties. Helping improve the indoor environment for personnel and equipment.
Your benefits at a glance:
- Increased safety and hygiene standards
- Fast opening speeds of up to 2 m/s
- Easy integration and optimized floor space
- Improved traffic flow and less downtime
- Reduced noise levels and energy loss
- Optional touchless entry
ASSA ABLOY HS9030G
ASSA ABLOY HS9030G is the most space-efficient high speed door for inside applications in the market. It is designed for use in places where sealing and aesthetics are important. To increase natural light, the door curtain can be equipped with windows or vision panels.
ASSA ABLOY HS7040
The high speed door ASSA ABLOY HS7040 for internal openings combines speed, safety and design and is therefore one of our most versatile high speed doors.
To increase productivity in the Manufacturing, Logistics and Retail Industry, the standard frequency converter control system provides one of the fastest and smoothest door speeds which helps to regulate the flow of traffic and goods.
Equipped with the break-away system, the door curtain automatically absorbs the impact and releases itself from the side frame. This reduces downtime. At the same time, the soft bottom profile limits damage to door and surrounding area.
The door is equipped with an intelligent pressure recognition system. With this, the door differentiates if an object is located under the door or if wind or drafts are creating pressure on the door curtain.
Airtight, high speed doors that offer complete safety.
HS-series Internal doors
ASSA ABLOY HS9010P high-speed door
- Medium-sized, max. 5500 x 5500 mm
- Heavy-duty operations
- Galvanised steel construction
- Unique direct door drive system
- Opening speed up to 2.4 m/s
ASSA ABLOY HS9010PL high-speed door
- Large-sized, max. 11000 x 5500 mm
- Heavy-duty operations
- Galvanised steel construction
- Unique direct door drive system
- Opening speed up to 0.8 m/s
ASSA ABLOY HS9110P high-speed door
- Medium-sized, max. 5500 x 5500 mm
- Heavy-duty operations
- Galvanised steel construction
- Unique enhanced direct door drive system
- Opening speed up to 2.4 m/s
ASSA ABLOY HS9020G high-speed door
- Medium-sized, max. 4000 x 4000 mm
- Wide range of applications
- Galvanised steel construction
- Gravity drive system
- Opening speed up to 1.2 m/s (Option: 2.0 m/s)
ASSA ABLOY HS9030G high-speed door
- Medium-sized, max. 3500 x 3500 mm
- Space saving design
- Galvanised steel construction
- Gravity drive system
- Opening speed up to 2.7 m/s
ASSA ABLOY HS7040 high-speed door
- For internal openings up to 4500 – 4600 mm
- Intelligent pressure recognition system
- Opening speed up to 2.3 m/s
- Frequency converter control for smooth door movement
- Optional Sustainability Plus: Additional insulated curtain and column seals available on request
BIM objects
Download these products as BIM objects here:
ASSA ABLOY HS9010P high-speed door
ASSA ABLOY HS9010PL high-speed door
ASSA ABLOY HS9110P high-speed door
| Product variations | Description |
|---|---|
|
HS7040
|
Modular (small and large openings), size up to 4000x4500mm, and soft bottom for increased safety.
|
|
HS9010P
|
Durable high usage, size up to 5500x5500mm, and break-away automatic reset system.
|
|
HS9010PL
|
Dual barrel drive system, size up to 11000x5500mm, and break-away automatic reset system.
|
|
HS9020G
|
Very high lifetime, 1000000 performance test, space saving side frames, and break-away automatic reset system.
|
|
HS9030G
|
Easy to operate emergency feature, opening speeds up to 2,0 m/s, soft bottom profile, and break-away automatic reset system.
|
|
HS9110P
|
Smooth and quiet operation, opening speeds up to 2,4 m/s, size up to 5500x5500mm, and break-away automatic reset system.
|
