HS-series External doors
High wind load resistance and fast opening speeds with ASSA ABLOY (previously Albany Doors) high speed exterior doors.
ASSA ABLOY high speed exterior doors suit many different applications and offer excellent high wind-load resistance. Their unique design provides virtually perfect sealing, making the doors airtight and protecting your environment against drafts, humidity and dirt.
High opening- and closing-speed ensures maximum efficiency and helps you save energy.
ASSA ABLOY high speed exterior doors guarantee the safety of your personnel and equipment thanks to absence of stiffeners combined with a flexible curtain that moulds itself. A motor driven by a frequency converter makes Albany high-speed exterior doors extremely reliable. Soft starts and stops increase the longevity of the motor considerably.
All ASSA ABLOY high speed exterior doors are equipped with a break-away system. They are also self-repairing to reduce production downtime and maintenance.
ASSA ABLOY HS8010P
ASSA ABLOY HS8010P is a medium-sized high-speed door for outside, heavy-duty applications. To increase natural light, the door curtain can be equipped with windows or vision panels. A curtain with an increased static insulation is available as an option.
ASSA ABLOY HS8010PL
ASSA ABLOY HS8010PL is a large-sized high-speed door for outside, heavy-duty operations. It can be equipped with windows or vision panels to increase natural lighting. A curtain with an increased static insulation is available as an option.
ASSA ABLOY HS8020P
ASSA ABLOY HS8020P is a medium-sized high-speed door for outside applications with high wind loads. The door has excellent wind resistance, up to class 5 (EN12424). For better lighting, the door curtain can be equipped with windows or vision panels. A curtain with an increased static insulation is available as an option.
ASSA ABLOY HS8020PL
ASSA ABLOY HS8020PL is a large-sized high speed door for outside applications. Reinforced side guides secure easy opening and closing at high wind loads. To increase natural lighting, the door curtain can be equipped with windows or vision panels.
High wind load resistance and fast opening speed.
HS-series External doors
ASSA ABLOY HS8010P high-speed door
- Medium-sized, max. 5500 x 5500 mm
- Heavy-duty operations
- Galvanised steel construction
- Unique direct door drive system
- Opening speed up to 2,4 m/s
ASSA ABLOY HS8010PL high-speed door
- Large-sized, max. 9000 x 5500 mm
- Heavy-duty operations
- Galvanised steel construction
- Unique direct door drive system
- Opening speed up to 0,8 m/s
ASSA ABLOY HS8020P high-speed door
- Medium-sized, max. 5500 x 5500 mm
- Heavy-duty operations
- High wind loads, up to class 5
- Galvanised steel construction
- Unique direct door drive system
- Opening speed up to 2,4 m/s
ASSA ABLOY HS8020PL high-speed door
- Large-sized, max. 8000 x 5500 mm
- Heavy-duty operations
- High wind loads, up to class 4
- Galvanised steel construction
- Unique direct door drive system
- Opening speed up to 0,8 m/s
BIM objects
Download these products as BIM objects here:
ASSA ABLOY HS8010P high-speed door
ASSA ABLOY HS8010PL high-speed door
| Product variations | Description |
|---|---|
|
HS8010P
|
High wind class - up to class 4, opening speed up to 2,4 m/s, size up to 5500x5500mm and break-away - an automatic reset system.
|
|
HS8010PL
|
Direct drive system, opening speed up to 1,4 m/s, size up to 9000x5500mm and break-away - an automatic reset system.
|
|
HS8020P
|
High wind class - up to class 5, opening speed up to 2,4 m/s, size up to 5500x5500mm and break-away - an automatic reset system.
|
|
HS8020PL
|
High wind class - up to class 4; opening speed up to 1,4 m/s, size up to 8000x5500mm and break-away - an automatic reset system.
|
